Binocular Adapter - Product Guide
Setting up for glassing should be straightforward. Our Binocular Adapter covers most binocular models, to help get you set up with the MagnaSwitch™ system on your gear and attaching them to a Hoplite, Ascent, Sentinel SpringBok Tripods and Davros Heads.
Subscribe to our YouTube Channel here.Overview
The Spartan Binocular Tripod Adapter is designed to maximise stability during glassing sessions. Its low-profile design allows it to fit easily inside a binocular harness while providing a secure mounting solution for tripod use.
Using the MagnaSwitch™ attachment system, the adapter allows binoculars to be attached to Spartan products such as the Hoplite, Sentinel, and Ascent tripods, as well as Davros heads, in just seconds. This enables hunters and observers to benefit from increased stability while scanning terrain or tracking wildlife.
The Binocular Tripod Adapter is available in three sizes (#1, #2, and #3) to accommodate different binocular models and body shapes.
Installing the Clamp
Place the binocular clamp around the binoculars in the desired position. For best stability, the clamp should be positioned near the centre of gravity of the binoculars.
Ensure that the slot for the square nut is facing toward the centre of the binoculars, then insert the square nut into the slot.
Select the screw length that properly engages the thread without protruding excessively. Using the provided Allen key, gently tighten the screw until the clamp is secure.
Avoid overtightening. The clamp should be snug and stable without rotating on the binocular housing.
Sizing Guide
The Binocular Tripod Adapter is available in three primary sizes to accommodate different binocular models.
- Size #1 – Compact binocular bodies
- Size #2 – Standard 42–50 mm binoculars
- Size #3 – Larger binoculars and rangefinding models
Some specialised models, such as the Swarovski EL Range, use a dedicated EL-Range size.
Common Binocular Models
Below are examples of common binocular models and their recommended adapter sizes.
Vortex +
| Model | Size |
|---|---|
| Razor UHD 8×42 | #2 |
| Razor UHD 10×42 | #2 |
| Razor UHD 10×50 | #2 |
| Razor UHD 12×50 | #2 |
| Razor UHD 18×56 | #2 |
| Razor HD 8×42 | #1 |
| Razor HD 10×42 | #1 |
| Razor HD 10×50 | #1 |
| Razor HD 12×50 | #1 |
| Viper HD 8×42 | #2 |
| Viper HD 10×42 | #2 |
| Viper HD 10×50 | #2 |
| Viper HD 12×50 | #2 |
| Viper HD 10×50 (Japan Model) | #3 |
| Viper HD 12×50 (Japan Model) | #3 |
| Viper HD 15×50 (Japan Model) | #3 |
| Diamondback (Non-HD) 8×42 | #2 |
| Diamondback (Non-HD) 10×42 | #2 |
| Diamondback (Non-HD) 10×50 | #3 |
| Diamondback (Non-HD) 12×50 | #3 |
| Diamondback HD 8×42 | #1 |
| Diamondback HD 10×42 | #1 |
| Diamondback HD 10×50 | #2 |
| Diamondback HD 12×50 | #2 |
| Diamondback HD 15×56 | #3 |
| Crossfire (Non-HD) 8×42 | #1 |
| Crossfire (Non-HD) 10×42 | #1 |
| Crossfire HD 8×42 | #1 |
| Crossfire HD 10×42 | #1 |
| Crossfire HD 10×50 | #3 |
| Crossfire HD 12×50 | #3 |
| Fury HD | #3 |
| Fury HD 5000 | #3 |
| Fury HD 5000 AB | #3 |
| Vulture 8.5×50 | #3 |
| Vulture 10×50 | #3 |
| Vulture 12×50 | #3 |
Swarovski +
| Model | Size |
|---|---|
| EL 8.5×42 | #2 |
| EL 10×42 | #2 |
| EL 10×50 | #3 |
| EL 12×50 | #3 |
| NL Pure 8×42 | #1 |
| NL Pure 10×42 | #1 |
| NL Pure 12×42 | #1 |
| SLC 8×42 | #2 |
| SLC 10×42 | #2 |
Leica +
| Model | Size |
|---|---|
| Geovid Pro 8×32 | #2 |
| Geovid Pro 10×32 | #2 |
| Geovid 8×42 BRF | #3 |
| Geovid 10×42 BRF | #3 |
| Geovid 8×42 HD | #3 |
| Geovid 10×42 HD | #3 |
| Geovid R 8×42 | #3 |
| Geovid R 10×42 | #3 |
| Geovid R 15×56 | #3 |
| Geovid HD-B 8×42 | #3 |
| Geovid HD-B 10×42 | #3 |
| Geovid HD-R 8×42 | #3 |
| Geovid HD-R 10×42 | #3 |
| Geovid HD-B 2200 8×42 | #3 |
| Geovid HD-B 2200 10×42 | #3 |
| Geovid HD-B 3000 8×42 | #3 |
| Geovid HD-B 3000 10×42 | #3 |
| Geovid HD-R 2700 8×42 | #3 |
| Geovid HD-R 2700 10×42 | #3 |
| Geovid 3200.com 8×42 | #3 |
| Geovid 3200.com 10×42 | #3 |
| Trinovid 8×40 | #1 |
| Trinovid 10×40 | #1 |
| Trinovid HD 8×42 | #1 |
| Trinovid HD 10×42 | #1 |
| Noctivid 8×42 | #2 |
| Noctivid 10×42 | #2 |
| Ultravid 7×42 | #2 |
| Ultravid 8×42 | #2 |
| Ultravid 10×42 | #2 |
| Ultravid 8×50 | #3 |
| Ultravid 10×50 | #3 |
| Ultravid 12×50 | #3 |
Zeiss +
| Model | Size |
|---|---|
| Victory SF 8×32 | #1 |
| Victory SF 10×32 | #1 |
| Victory SF 8×42 | #2 |
| Victory SF 10×42 | #2 |
| Victory RF 8×42 | #3 |
| Victory RF 10×42 | #3 |
| Victory HT 8×42 | #2 |
| Victory HT 10×42 | #2 |
| Conquest HD 8×32 | #1 |
| Conquest HD 10×32 | #1 |
| Conquest HD 8×42 | #2 |
| Conquest HD 10×42 | #2 |
| Terra ED 8×42 | #2 |
| Terra ED 10×42 | #2 |
| SFL 8×40 | #1 |
| SFL 10×40 | #1 |
| Classic 10×40 | #1 |
Leupold +
| Model | Size |
|---|---|
| Acadia 8×42 | #2 |
| Acadia 10×42 | #2 |
| Yellowstone 10×42 | #1 |
| BX-1 McKenzie 8×42 | #2 |
| BX-1 McKenzie 10×42 | #2 |
| BX-1 McKenzie 10×50 | #3 |
| BX-1 McKenzie 12×50 | #3 |
| BX-2 Acadia 8×42 | #3 |
| BX-2 Acadia 10×42 | #3 |
| BX-2 Alpine HD 8×42 | #1 |
| BX-2 Alpine HD 10×42 | #1 |
| BX-2 Alpine HD 10×52 | #3 |
| BX-2 Alpine HD 12×52 | #3 |
| BX-T HD 10×42 MIL-L | #1 |
| BX-4 Pro Guide HD 8×42 | #1 |
| BX-4 Pro Guide HD 10×42 | #1 |
| BX-4 Pro Guide HD 10×50 | #1 |
| BX-4 Pro Guide HD 12×50 | #1 |
| BX-5 Santiam HD 8×42 | #1 |
| BX-5 Santiam HD 10×42 | #1 |
| BX-5 Santiam HD 10×50 | #2 |
| BX-5 Santiam HD 12×50 | #2 |
Nikon +
| Model | Size |
|---|---|
| Prostaff 3S 8×42 | #2 |
| Prostaff 3S 10×42 | #2 |
| Prostaff 5 10×50 | #3 |
| Prostaff 5 12×50 (P511) | #3 |
| Prostaff 7(S) 8×42 | #2 |
| Prostaff 7(S) 10×42 | #2 |
| Prostaff P3 8×30 | #1 |
| Prostaff P3 10×30 | #1 |
| Prostaff P3 8×42 | #2 |
| Prostaff P3 10×42 | #2 |
| Prostaff P7 8×30 | #1 |
| Prostaff P7 10×30 | #1 |
| Prostaff P7 8×42 | #2 |
| Prostaff P7 10×42 | #2 |
| Monarch ATB 8×42 | #2 |
| Monarch ATB 10×42 (M511) | #2 |
| Monarch ATB 12×42 | #2 |
| Monarch 3 8×42 | #2 |
| Monarch 3 10×42 | #2 |
| Monarch 5 8×42 | #2 |
| Monarch 5 10×42 | #2 |
| Monarch 5 12×42 | #2 |
| Monarch M5 8×42 | #2 |
| Monarch M5 10×42 | #2 |
| Monarch M5 12×42 | #2 |
| Monarch 7 8×42 | #2 |
| Monarch 7 10×42 | #2 |
| Monarch M7 8×30 | #1 |
| Monarch M7 10×30 | #1 |
| Monarch M7 8×42 | #2 |
| Monarch M7 10×42 | #2 |
| Monarch HG 8×42 | #2 |
| Monarch HG 10×42 | #2 |
| Laserforce 10×42 | #3 |
| Aculon 10×42 | #2 |
| Aculon 10–22×50 | #2 |
Maven +
| Model | Size |
|---|---|
| B.1 8×42 | #2 |
| B.1 10×42 | #2 |
| B1.2 8×42 | #2 |
| B.2 7×45 | #2 |
| B.2 9×45 | #2 |
| B.2 11×45 | #2 |
| B.5 10×56 | #3 |
| B.5 12×56 | #3 |
| B.5 15×56 | #3 |
| B.5 18×56 | #3 |
| B.6 10×50 | #2 |
| B.6 12×50 | #2 |
| C.1 8×42 | #2 |
| C.1 10×42 | #2 |
| C.1 12×42 | #2 |
| C.3 10×50 | #3 |
| C.3 12×50 | #3 |
Meopta +
| Model | Size |
|---|---|
| Meostar B1 Plus 8×42 HD | #2 |
| Meostar B1 Plus 10×42 HD | #2 |
| Optika HD 8×42 | #1 |
| Optika HD 10×42 | #1 |
| Optika LR 10×42 HD | #2 |
| MeoPro Air 8×42 HD | #2 |
| MeoPro Air 10×42 HD | #2 |
Sig Sauer +
| Model | Size |
|---|---|
| Zulu5 HD 10×42 | #2 |
| Zulu5 HD 12×42 | #2 |
| Zulu7 HDX 8×42 | #2 |
| Zulu7 HDX 10×42 | #2 |
| Zulu9 HDX 9×45 | #3 |
| Zulu9 HDX 11×45 | #3 |
| Zulu9 HDX 15×56 | #3 |
| Kilo 3000 10×42 | #3 |
| Kilo 10KABS HD | #3 |
Vanguard +
| Model | Size |
|---|---|
| Endeavor ED 8×42 | #2 |
| Endeavor ED 10×42 | #2 |
| Endeavor ED II 8×42 | #2 |
| Endeavor ED II 10×42 | #2 |
| Endeavor ED IV 8×42 | #2 |
| Endeavor ED IV 10×42 | #2 |
| Veo ED 8×42 | #2 |
| Veo ED 10×42 | #2 |
| Veo HD 8×42 | #2 |
| Veo HD 10×42 | #2 |
| Veo HD II 8×42 | #2 |
| Veo HD II 10×42 | #2 |
| Spirit XF 8×42 | #2 |
| Spirit XF 10×42 | #2 |
Bushnell +
| Model | Size |
|---|---|
| Fusion X 10×42 | #3 |
| Fusion 10×42 Rangefinder | #2 |
| Legend 8×42 | #2 |
| Legend 10×42 | #2 |
| Legend 10×50 | #3 |
| Legend 12×50 | #3 |
| Prime 10×42 | #2 |
Tract +
| Model | Size |
|---|---|
| Toric UHD 8×42 | #2 |
| Toric UHD 10×42 | #2 |
| Toric UHD 10×50 | #3 |
| Toric UHD 12.5×50 | #3 |
Athlon +
| Model | Size |
|---|---|
| Neos G2 HD 8×42 | #1 |
| Neos G2 HD 10×42 | #1 |
| Talos G2 HD 8×42 | #1 |
| Talos G2 HD 10×42 | #1 |
| Argos G2 8×42 | #1 |
| Argos G2 10×42 | #1 |
| Argos G2 10×50 | #1 |
| Argos G2 12×50 | #1 |
| Argos G2 UHD 8×42 | #1 |
| Argos G2 UHD 10×42 | #1 |
| Midas 8×42 | #2 |
| Midas 10×42 | #2 |
| Midas G2 UHD 8×42 | #1 |
| Midas G2 UHD 10×42 | #1 |
| Midas G2 UHD 10×50 | #3 |
| Midas G2 UHD 12×50 | #3 |
| Cronus UHD 10×50 (RF Model) | #3 |
| Cronus G2 UHD 10×42 | #1 |
Steiner +
| Model | Size |
|---|---|
| Predator 8×42 | #2 |
| Predator 10×42 | #2 |
| Predator 10×42 LRF | #2 |
| Wildlife XP 10×44 | #2 |
| XC 8×42 | #2 |
| XC 10×42 | #2 |
| HX 8×42 | #3 |
| HX 10×42 | #3 |
| T 10×42 | #2 |
| Safari Ultrasharp 10×42 | #2 |
| BluHorizons 10×42 | #2 |
Kowa +
| Model | Size |
|---|---|
| Genesis Prominar 8.5×44 | #2 |
| Genesis Prominar 10.5×44 | #2 |
| BDII 8×42 | #2 |
| BDII 10×42 | #2 |
| SVII 8×32 | #1 |
| SVII 10×32 | #1 |
Choosing the right size ensures a secure and stable fit for your binoculars, enhancing your viewing experience in the field.
Don't See your Model ?
Step 1: Gather Your Tools
Binoculars
A short section small diameter string
A ruler or tape measure
A Sharpie (optional, but helpful)
Step 2: Measure the Circumference
Wrap the string tightly around the binoculars where you want the adapter to be mounted. Mark the string where it completes a full circle.
Step 3: Measure and Compare
Measure the length of the string with a ruler to find the circumference. Use the sizing chart below to find your adapter size:
|
Size |
Smallest (Metric) |
Largest (Metric) |
Smallest (Imperial) |
Largest (Imperial) |
|
Size 1 |
14.4 cm |
16.0 cm |
5 11/16" |
6 5/16" |
|
Size 2 |
15.7 cm |
17.3 cm |
6 3/16" |
6 13/16" |
|
Size 3 |
17.0 cm |
18.6 cm |
6 11/16" |
7 5/16" |
Method 2: Using Calipers
Step 1: Measure the Diameter
Using calipers, take two measurements of the diameter at the chosen mounting location. Average these measurements if your binoculars are not perfectly round.
Step 2: Compare with the Chart Below
Match your diameter measurements with the chart below to determine the correct adapter size:
|
Size |
Smallest (inches) |
Largest (inches) |
|
1 |
1.810 |
2.010 |
|
2 |
1.970 |
2.160 |
|
3 |
2.130 |
2.320 |
Choosing the right size ensures a secure and stable fit for your binoculars, enhancing your viewing experience in the field.
Need More Help?
If you have any questions, concerns, or issues, please don't hesitate to contact us at: help@javelinbipod.com
